Dunkermotoren E600R Power-Off Brake

Name: E600R Dunkermotoren E600R Power-Off Brake
SKU: E600R

The Dunkermotoren E600R is the highest-torque power-off brake in the Dunkermotoren range, rated at 7 Nm nominal torque on a 24 Vdc supply with a torque range of 7.00–9.00 Nm over the temperature range. It is based on spring force, a design that is particularly robust and insensitive to temperature and load changes. The E600R draws 0.61 A at 14.7...

The E600R draws 0.61 A at 14.7 W nominal input power, with a 20 ms activation time and an 85 ms deactivation time. It measures 84 mm in diameter by 50 mm long, weighs 0.9 kg and runs with low noise. Protection class is IP20 as supplied; brakes can be mounted openly or with covers in protection class up to IP65, and in combination with brushless motors they can be integrated into the motor profile housing at IP65. The E600R pairs with BG95 motors in that configuration. Connection is by 500 mm AWG24 leads, blue for GND and red for Vdc.

All rated values apply in the run-in condition.

Show Less

Select model number

Model:

or send a quick enquiry about this product only

Dunkermotoren E600R spring-applied power-off brake with metallic housing, central bore and mounting pins

Features

Spring-force power-off design holds the load when the 24 Vdc supply is removed: the axis stays put on power loss with no holding current
7 Nm nominal holding (7.00–9.00 Nm over temperature): the highest torque in the range, for the heaviest axes and largest motors
Insensitive to temperature and load changes, so holding stays predictable through duty cycling and thermal swings
Low-noise operation for quiet installations
Integrates with BG 95 motors inside an IP65 profile housing, or mounts open at IP20, up to IP65 with covers
20 ms engage / 85 ms release timing tuned for controlled holding on high-inertia loads
500 mm AWG 24 flying leads (blue GND, red Vdc) for direct wiring, no adapters or extra tails

Specifications

POWER-OFF BRAKE SPECIFICATIONS
Nominal voltage	Vdc	24
Nominal torque⁽¹⁾	Nm	7
Torque range⁽¹⁾⁽²⁾	Nm	7.00–9.00
Nominal current⁽¹⁾	A	0.61
Nominal input power⁽¹⁾	W	14.7
Activation time	ms	20
Deactivation time	ms	85
Protection class	IP	20
Weight	kg	0.9
Noise	–	low noise
Diameter (Ø)	mm	84
Length (L)	mm	50
Strand colour GND	–	blue
Strand colour Vdc	–	red
Strand length	mm	500
Strand type / cross section	–	AWG 24
(1) Values valid in run-in condition
(2) Over the temperature

Downloads

dunkermotoren-e-600-r-24vdc-spring-force-power-off-brake-datasheet.pdf

Warranty & Returns

Warranty periods vary by product. Please refer to the Powerbox Warranty Policy for the applicable coverage period against manufacturing defects from date of purchase. For returns and RMA requests, please visit our RMA support page or contact our support team directly.

FAQs

What torque does the Dunkermotoren E600R hold?

The E600R is rated at 7 Nm nominal torque with a 7.00–9.00 Nm range over temperature on a 24 Vdc supply: the highest-torque brake in the Dunkermotoren power-off series, more than double the 3.3 Nm E310R below it.

How does a power-off brake work, and when should I specify one?

A power-off brake holds the load when supply voltage is removed and releases when it is applied, so the axis is held automatically on power loss, emergency stop or shutdown. Specify one wherever a vertical axis, gravity load or positioning stage must not drift while the drive is de-energised: it is a holding brake, not a service brake for decelerating a moving load.

What are the full electrical ratings of the E600R?

It runs on 24 Vdc drawing 0.61 A at 14.7 W nominal input power, engages in 20 ms and releases in 85 ms. All rated values apply in the run-in condition, and the torque range applies over the temperature range.

Why is the release time longer on the E600R than on the smaller brakes?

At 85 ms the E600R has the longest deactivation time in the series, against 65 ms for the E310R and 20–30 ms for the smaller models. That is a consequence of the larger spring and armature needed to generate 7 Nm. Engagement is unaffected at 20 ms, matching the E310R: the brake still catches the load quickly on power loss; it simply takes marginally longer to free the axis on start-up, which is worth allowing for in cycle timing.

Which motors does the E600R integrate with at IP65?

In an IP65 extruded-body installation the E600R is listed with the BG 95 motor, giving an overall length of 65 mm. Mounted openly or with covers it can be fitted to other motors in the range. Send your motor model to sales@powerbox.com.au to confirm the arrangement.

What are the dimensions and connection details of the E600R?

The E600R measures 84 mm in diameter by 50 mm long and weighs 0.9 kg, the largest and heaviest brake in the series. It is supplied with 500 mm AWG 24 leads, blue for GND and red for Vdc. It is also rated low noise.

What IP rating does the E600R have, and can it be used in a sealed assembly?

The brake itself is IP20 as supplied. Brakes can be mounted to the motor openly or with covers in protection class up to IP65, and in combination with brushless motors they can be integrated into the motor profile housing at IP65, so the achievable rating depends on the mounting arrangement rather than on the brake alone.

How do I select the right brake for my Dunkermotoren motor?

Selection depends on the holding torque required at the axis, the motor series the brake mounts to, and whether an IP65 profile-housing installation is needed. Send your motor model and load details to sales@powerbox.com.au and Powerbox will confirm the right brake and mounting arrangement.
