DC/DC Converters

ZVS BUCK REGULATORS- VICHIP PICOR COOL-POWER



Read More

View Models
ZVS BUCK REGULATORS- VICHIP PICOR COOL-POWER
NRND Not Recommended for New Design
Specifications
GENERAL
Input Voltage

12 V nominal (8 to 18 V)

24 V nominal (8 to 36 V)

48 V nominal (30 to 60 V)
Output Voltage Wide output range (1 – 16 V)
Output Current 10, 15 and up to 22 Amps
Efficiency

Up to 98%

Light load and full load

high efficiency performance
Dimensions

LGA SiP :

10 x 14 x 2.56 mm

10 x 10 x 2.56 mm

BGA SiP :

10.5 x 14.5 x 3.05 mm



Selection Table
MODEL NUMBER

INPUT VOLTAGE

Range (V)

OUTPUT VOLTAGE

Set (V)

OUTPUT VOLTAGE

Range (V)

OUTPUT CURRENT

Max (A)
Input: 12V (8 - 18Vin)
PI3420-00-LGIZ  12 (8 – 18)V 1.0V 1.0  – 1.4V 15A
PI3421-00-LGIZ  12 (8 – 18)V 1.8V 1.4 – 2.0V 15A
PI3422-00-LGIZ 12 (8 – 18)V 2.5V 2.0 – 3.1V 15A
PI3423-00-LGIZ  12 (8 – 18)V 3.3V 2.3 – 4.1V 15A
PI3424-00-LGIZ  12 (8 – 18)V 5.0V 3.3 – 6.5V 15A

Input: 24V (8 - 36Vin)
PI3311-00-LGIZ  24 (8 – 36)V 1.0V 1.0 – 1.4V 10A
PI3318-00-LGIZ  24 (8 – 36)V 1.8V 1.4 – 2.0V 10A
PI3312-00-LGIZ  24 (8 – 36)V 2.5V 2.0 – 3.1V 10A
PI3301-00-LGIZ  24 (8 – 36)V 3.3V 2.3 – 4.1V 10A
PI3302-00-LGIZ  24 (8 – 36)V 5.0V 3.3 – 6.5V 10A
PI3303-00-LGIZ 24 (8 – 36)V 12.0V 6.5 - 13.0V  8A
 PI3305-00-LGIZ 24 (8 – 36)V 15.0V  10.0 - 16.0V  8A
24V (8 - 36Vin) High Current
PI3311-01-LGIZ  24 (8 – 36)V 1.0V 1.0 – 1.4V 15A
PI3318-01-LGIZ  24 (8 – 36)V 1.8V 1.4 – 2.0V 15A
PI3312-01-LGIZ  24 (8 – 36)V 2.5V 2.0 – 3.1V 15A
PI3301-01-LGIZ  24 (8 – 36)V 3.3V 2.3 – 4.1V 15A
PI3302-03-LGIZ 24 (8 – 36)V 5V 3.3 - 6.5V 15A
 24Vin (8-36Vin) I2C Functionality
PI3311-20-LGIZ  24 (8 – 36)V 1.0V 1.0 – 1.4V 10A
PI3318-20-LGIZ  24 (8 – 36)V 1.8V 1.4 – 2.0V 10A
PI3312-20-LGIZ  24 (8 – 36)V 2.5V 2.0 – 3.1V 10A
PI3301-20-LGIZ  24 (8 – 36)V 3.3V 2.3 – 4.1V 10A
PI3302-20-LGIZ  24 (8 – 36)V 5.0V 3.3 – 6.5V 10A
PI3303-20-LGIZ 24 (8 – 36)V 12.0V 6.5 – 13.0V 8A
PI3305-20-LGIZ 24 (8 – 36)V 15.0V 10.0 – 16.0V 8A
PI3311-21-LGIZ  24 (8 – 36)V 1.0V 1.0 – 1.4V 15A
PI3318-21-LGIZ  24 (8 – 36)V 1.8V 1.4 – 2.0V 15A
PI3312-21-LGIZ  24 (8 – 36)V 2.5V 2.0V - 3.1V 15A
PI3301-21-LGIZ  24 (8 – 36)V 3.3V 2.3 – 4.1V 15A
48V (30-60Vin)
PI3525-00-LGIZ 48 (36 – 60)V 5.0V 4.0 - 6.5V 20A
48V (30-60Vin)
PI3542-00-LGIZ  48 (36 – 60)V 2.5V 2.2 – 3.0V 10A
PI3543-00-LGIZ  48 (36 – 60)V 3.3V 2.6 – 3.6V 10A
PI3545-00-LGIZ  48 (36 – 60)V 5.0V 4.0 – 5.5V 10A
PI3546-00-LGIZ  48 (36 – 60)V 12.0V 6.5 – 14.0V 9A
